1-R1-11 HİDROLİK BSP SOMUNLU İÇE HAVŞA DİRSEK REKO

BSP İÇE HAVŞA SOMUNLU 90° HORTUM RAKORLARI
BSP FEMALE 30° FLARE 90° ELBOW SWIVEL HOSE FITTINGS

HORTUM ÖLÇÜSÜ
HOSE SIZE

SOMUN ÖLÇÜSÜ
NUT SIZE

B

C

E

ØD

AA

mm

inch

06

1/4

R1/4-19

50

25

27

4

17

06

1/4

R3/8-19

50

25

29

4

22

06

1/4

R1/2-14

50

25

31

4

27

08

5/16

R3/8-19

55

28

30

5.5

22

08

5/16

R1/2-14

55

28

32

5.5

27

10

3/8

R3/8-19

61.5

32.5

33

7

22

10

3/8

R1/2-14

61.5

32.5

37

7

27

12

1/2

R1/2-14

69.5

37.5

37

9

27

16

5/8

R3/4-14

84

45

54

12

32

19

3/4

R3/4-14

100

57

51

14

32

25

1"

R1"-11

122

69

66

19

41

32

1"1/4

R1"1/4-11

140

80

87

25

50

38

1"1/2

R1"1/2-11

175

105

100

29

55
